Product: Phospho-KSR1(Ser392) Antibody
Catalog: AF2358
Description: Rabbit polyclonal antibody to Phospho-KSR1(Ser392)
Application: WB IHC
Reactivity: Human, Mouse
Prediction: Pig, Bovine, Rabbit, Dog, Chicken
Mol.Wt.: 115kDa; 102kD(Calculated).
Uniprot: Q8IVT5
RRID: AB_2845372

View similar products>>

   Size Price Inventory
 100ul $280 In stock
 200ul $350 In stock

Lead Time: Same day delivery

For pricing and ordering contact:
Local distributors

Product Info

Source:
Rabbit
Application:
WB 1:500-1:2000, IHC 1:50-1:200
*The optimal dilutions should be determined by the end user.
*Tips:

WB: For western blot detection of denatured protein samples. IHC: For immunohistochemical detection of paraffin sections (IHC-p) or frozen sections (IHC-f) of tissue samples. IF/ICC: For immunofluorescence detection of cell samples. ELISA(peptide): For ELISA detection of antigenic peptide.

Reactivity:
Human,Mouse
Prediction:
Pig(100%), Bovine(100%), Rabbit(100%), Dog(100%), Chicken(92%)
Clonality:
Polyclonal
Specificity:
Phospho-KSR1 (Ser392) Antibody detects endogenous levels of KSR1 only when phosphorylated at Ser392 in mouse, Or Ser406 in human.
RRID:
AB_2845372
Cite Format: Affinity Biosciences Cat# AF2358, RRID:AB_2845372.
Conjugate:
Unconjugated.
Purification:
The antibody is from purified rabbit serum by affinity purification via sequential chromatography on phospho-peptide and non-phospho-peptide affinity columns.
Storage:
Rabbit IgG in phosphate buffered saline , pH 7.4, 150mM NaCl, 0.02% sodium azide and 50% glycerol. Store at -20 °C. Stable for 12 months from date of receipt.
Alias:

Fold/Unfold

BKSR 1; BKSR1; dKsr; EK 31; EK31; hb; Kinase suppressor of Ras 1; Kinase suppressor of ras; KSR 1; KSR; KSR1; KSR1_HUMAN; Positive Ras signaling mediator family member (86.4 kD); Positive Ras signaling mediator family member; RSU 2; RSU2; SR 31; SR31; Suppressor of activated let 60 Ras SUR3; Suppressor of Ras1 31;

Immunogens

Immunogen:
Uniprot:
Gene(ID):
Sequence:
MDRAALRAAAMGEKKEGGGGGDAAAAEGGAGAAASRALQQCGQLQKLIDISIGSLRGLRTKCAVSNDLTQQEIRTLEAKLVRYICKQRQCKLSVAPGERTPELNSYPRFSDWLYTFNVRPEVVQEIPRDLTLDALLEMNEAKVKETLRRCGASGDECGRLQYALTCLRKVTGLGGEHKEDSSWSSLDARRESGSGPSTDTLSAASLPWPPGSSQLGRAGNSAQGPRSISVSALPASDSPTPSFSEGLSDTCIPLHASGRLTPRALHSFITPPTTPQLRRHTKLKPPRTPPPPSRKVFQLLPSFPTLTRSKSHESQLGNRIDDVSSMRFDLSHGSPQMVRRDIGLSVTHRFSTKSWLSQVCHVCQKSMIFGVKCKHCRLKCHNKCTKEAPACRISFLPLTRLRRTESVPSDINNPVDRAAEPHFGTLPKALTKKEHPPAMNHLDSSSNPSSTTSSTPSSPAPFPTSSNPSSATTPPNPSPGQRDSRFNFPAAYFIHHRQQFIFPVPSAGHCWKCLLIAESLKENAFNISAFAHAAPLPEAADGTRLDDQPKADVLEAHEAEAEEPEAGKSEAEDDEDEVDDLPSSRRPWRGPISRKASQTSVYLQEWDIPFEQVELGEPIGQGRWGRVHRGRWHGEVAIRLLEMDGHNQDHLKLFKKEVMNYRQTRHENVVLFMGACMNPPHLAIITSFCKGRTLHSFVRDPKTSLDINKTRQIAQEIIKGMGYLHAKGIVHKDLKSKNVFYDNGKVVITDFGLFGISGVVREGRRENQLKLSHDWLCYLAPEIVREMTPGKDEDQLPFSKAADVYAFGTVWYELQARDWPLKNQAAEASIWQIGSGEGMKRVLTSVSLGKEVSEILSACWAFDLQERPSFSLLMDMLEKLPKLNRRLSHPGHFWKSADINSSKVVPRFERFGLGVLESSNPKM

Predictions

Predictions:

Score>80(red) has high confidence and is suggested to be used for WB detection. *The prediction model is mainly based on the alignment of immunogen sequences, the results are for reference only, not as the basis of quality assurance.

Species
Results
Score
Pig
100
Bovine
100
Dog
100
Rabbit
100
Chicken
92
Horse
0
Sheep
0
Xenopus
0
Zebrafish
0
Model Confidence:
High(score>80) Medium(80>score>50) Low(score<50) No confidence

PTMs - Q8IVT5 As Substrate

Site PTM Type Enzyme
K61 Ubiquitination
Y162 Phosphorylation
K169 Ubiquitination
S184 Phosphorylation
S202 Phosphorylation
S229 Phosphorylation
S238 Phosphorylation
T240 Phosphorylation
S244 Phosphorylation
T250 Phosphorylation
S257 Phosphorylation
T261 Phosphorylation
S267 Phosphorylation
T270 Phosphorylation
T273 Phosphorylation
T274 Phosphorylation
T288 Phosphorylation
S293 Phosphorylation
S309 Phosphorylation
S311 Phosphorylation
S314 Phosphorylation
S331 Phosphorylation
S334 Phosphorylation
S351 Phosphorylation
T404 Phosphorylation
S406 Phosphorylation O43318 (MAP3K7) , P15531 (NME1)
S409 Phosphorylation
T425 Phosphorylation
T473 Phosphorylation
S478 Phosphorylation
Y552 Phosphorylation
S569 Phosphorylation
S597 Phosphorylation
T599 Phosphorylation
K656 Acetylation
K702 Ubiquitination
K709 Acetylation
Y723 Phosphorylation
T844 Phosphorylation
S888 Phosphorylation P17612 (PRKACA)
K903 Ubiquitination

PTMs - Q8IVT5 As Enzyme

Substrate Site Source
P04049 (RAF1) T269 Uniprot

Research Backgrounds

Function:

Part of a multiprotein signaling complex which promotes phosphorylation of Raf family members and activation of downstream MAP kinases (By similarity). Independently of its kinase activity, acts as MAP2K1/MEK1 and MAP2K2/MEK2-dependent allosteric activator of BRAF; upon binding to MAP2K1/MEK1 or MAP2K2/MEK2, dimerizes with BRAF and promotes BRAF-mediated phosphorylation of MAP2K1/MEK1 and/or MAP2K2/MEK2. Promotes activation of MAPK1 and/or MAPK3, both in response to EGF and to cAMP (By similarity). Its kinase activity is unsure (By similarity). Some protein kinase activity has been detected in vitro, however the physiological relevance of this activity is unknown (By similarity).

PTMs:

Phosphorylated on Ser-311 and, to a higher extent, on Ser-406 by MARK3. Dephosphorylated on Ser-406 by PPP2CA. In resting cells, phosphorylated KSR1 is cytoplasmic and in stimulated cells, dephosphorylated KSR1 is membrane-associated. Phosphorylated by PKA at Ser-888. Phosphorylation at Ser-888 is required for cAMP-dependent activation of MAPK1 and/or MAPK3 (By similarity).

Subcellular Location:

Cytoplasm. Membrane>Peripheral membrane protein. Cell membrane>Peripheral membrane protein. Cell projection>Ruffle membrane. Endoplasmic reticulum membrane.
Note: In unstimulated cells, where the phosphorylated form is bound to a 14-3-3 protein, sequestration in the cytoplasm occurs. Following growth factor treatment, the protein is free for membrane translocation, and it moves from the cytoplasm to the cell periphery.

Extracellular region or secreted Cytosol Plasma membrane Cytoskeleton Lysosome Endosome Peroxisome ER Golgi apparatus Nucleus Mitochondrion Manual annotation Automatic computational assertionSubcellular location
Subunit Structure:

Homodimer. Heterodimerizes (via N-terminus) with BRAF (via N-terminus) in a MAP2K1/MEK1 or MAP2K2/MEK2-dependent manner. Interacts with MAP2K1/MEK1 and MAP2K2/MEK2. Binding to MAP2K1/MEK1 releases the intramolecular inhibitory interaction between KSR1 N-terminus and kinase domains which is required for the subsequent RSK1 dimerization with BRAF. Identified in a complex with AKAP13, MAP2K1 and BRAF (By similarity). Interacts with AKAP13 and BRAF. Interacts with RAF and MAPK/ERK, in a Ras-dependent manner (By similarity). Interacts with 14-3-3 proteins including YWHAB (By similarity). Interacts with HSP90AA1/HSP90, YWHAE/14-3-3 and CDC37. The binding of 14-3-3 proteins to phosphorylated KSR1 prevents the membrane localization (By similarity). Interacts with MARK3 (By similarity). Interacts with PPP2R1A and PPP2CA (By similarity). Interacts with isoform 1 of VRK2.

Family&Domains:

The protein kinase domain is predicted to be catalytically inactive. The domain is sufficient for KSR1 and KSR1-mediated MAP2K1 and MAP2K2 membrane localization. The domain is required but not sufficient for MAP kinase-mediated inhibition of ELK1 phosphorylation (PubMed:10409742).

The N-terminal region mediates interaction with BRAF (PubMed:29433126). Also mediates membrane localization (By similarity).

Belongs to the protein kinase superfamily. TKL Ser/Thr protein kinase family.

Research Fields

· Environmental Information Processing > Signal transduction > Ras signaling pathway.   (View pathway)

· Human Diseases > Infectious diseases: Bacterial > Tuberculosis.
